PRIMARY APPLICATION: high quality at a very attractive price. Ideal for use as transmitters in stand-alone applications. Adjustable power output from 20 to 100%.
AUDIO PERFORMANCE: low distortion and intermodulation values and a high noise/signal ratio.
HARDWARE FEATURES: compact and indeformable thanks to the stainless steel chassis, in 3 rack units only.
USER-FRIENDLY FEATURES: four pushbuttons for user/device interaction and software that offers a simple, intuitive interface.
EASE OF MAINTENANCE: advanced module engineering ensures extreme of access and simple maintenance.
OPERATING EFFICIENCY: incorporate 3 PFC (Power Factor Corrector) power supplies in a redundant configuration, that provides the utmost efficiency for enhanced energy saving and environmental protection, which added to LD-MOSFET technology ensure high efficiency, better than 70% across the bandwidth.
RELIABILITY/CONTINUITY: APC (Automatic Power Control) and Foldback protection ensure reliable operation under any operating conditions.
INTERFACE CONTROL: total control thanks to microprocessor easily programmed from menu with all key parameters displayed on LCD.
INPUT/OUTPUT INTERFACE: built-in high-performance stereo coder, L&R analogue audio inputs, Mono inputs, MPX composite signal and auxiliary inputs for SCA / RDS signals.
RDS APPLICATION: built-in RDS encoder with UECP standard functions (option).
REMOTE CONTROL: built-in telemetry system via GSM modem, battery and battery charger or via WEB or via SNMP (option).
REGULATORY COMPLIANCE: state-of-the-art technology in full compliance with EC, FCC and CCIR standards.
Frequency range: FCC - CCIR - OIRT - JPN - CHN
Rated output power: 3500 W
AC Power input:
Active power Consumption: typical 5000W
Connector: Terminal Block
Dimensions: 483mm x 132mm x 675mm
Weight: About 31 kg
For more informations please read the Brochure in "Learn More"
