Denon DN-312X 12-Channel Line Mixer with Priority

Denon DN-312X 12-Channel

The DN-312X is a 1U 12-channel rack-mounted mixer that can solve countless audio problems. It has 6 combined mic/line inputs (Denon-Marantz proprietary HDHQ™ pre-microphones) each with switchable phantom power and 6 additional line inputs. It has balanced XLR outputs, a 1/4-inch (6.3 mm) mono output that can be used to connect the DN-312X to a remote mixer, a pair of stereo RCA outputs to connect to a remote recording device, and a 1/4-inch (6.3 mm) microphone monitoring port that can be used to monitor microphone signals.

Limited special offer
€322.20 No tax €358.00
-10%
Size chart
Women's clothing size
SizeXSSML
Euro 32/34 36 38 40
USA 0/2 4 6 8
Bust(in) 31-32 33 34 36
Bust(cm) 80.5-82.5 84.5 87 92
Waist(in) 24-25 26 27 29
Waist(cm) 62.5-64.5 66.5 69 74
Hips(in) 34-35 36 37 39
Hips(cm) 87.5-89.5 91.5 94 99
How To Measure Your Bust

With your arms relaxed at your sides, measure around the fullest part of your chest.

How To Measure Your Waist

Measure around the narrowest part of your natural waist, generally around the belly button. To ensure a comfortable fit, keep one finger between the measuring tape and your body.

Reference:
DN-312X 12 Denon 12 Canali Rackmixer Professionale
Brand:
Love0
Add to compare0
Add to wishlist
Description

Denon DN-312X 12-Channel Professional

Features:

  • 6 HDHQ™ combined inputs with MIC, phantom and line selectors
  • 6 mono RCA inputs (3 stereo)
  • 1/4" mic monitor output for private listening to all microphone inputs
  • Balanced XLR line outputs
  • 1/4" Mono line output can be used to feed audio to external recording device
  • AC or 24V DC power inputs
  • Mic 1 Priority control
  • Master and individual level controls
  • 1U rack mountable



Technical specifications:

Input Channels

Microphone input: 6 balanced XLR connectors (channels 1-6)

Frequency response: 20 Hz - 22 kHz

THD+N: < 0.03% @ 1 kHz

Sensitivity: -40 dBu

Maximum input: -19 dBu

Maximum voltage gain:

60 dB (Mic Input to Line Out, Mic Out & Mono Out)

50 dB (Mic Input to Rec Out)

Signal to noise ratio: > 103 dB

Phantom power supply: 18-21V, switch control

Line inputs: 6 balanced XLR connectors (channels 1-6)

Frequency response: 20 Hz - 22 kHz

THD+N: < 0.03% @ 1 kHz

Sensitivity: 0 dBu

Maximum input: +21 dBu

Maximum voltage gain:

20 dB (Mic Input to Line Out, Mic Out & Mono Out)

10 dB (Mic Input to Rec Out)

Signal to noise ratio: > 103 dB

Line inputs: Balanced stereo RCA connectors (channels 7/8-11/12)

Frequency response: 20 Hz - 22 kHz

THD+N: < 0.03% @ 1 kHz

Sensitivity: +10 dBu

Maximum input: +21 dBu

Maximum voltage gain:

10 dB (line input to line output)

0 dB (from line input to recording output)

4 dB (line input to mono output)

Signal to noise ratio: > 103 dB

Impedance:

Mic/Line input: 1.4 kΩ

Line input: > 10 kΩ

All outputs: 120 Ω

Equalizer

High: +15 dB at 12 kHz

Mid: +12 dB at 2.5 kHz

Low: +15 dB @ 80 Hz

Crosstalk

Adjacent entrances:

< -70 dB @ 1 kHz (channels 1-6)

< -68 dB @ 1 kHz (channels 7/8-11/12)

From input to output:

< -82 dB @ 1 kHz

Main MixOutput

Line output: 0 dBu (+2 dBu), balanced

Microphone output, mono output: 0 dBu (+2 dBu), unbalanced

Maximum output: +21 dBu balanced/unbalanced, 1/4" (6.35mm) jack

Noise (Bus): < -83 dB @ 20 Hz - 22 kHz

General

Mains connection: IEC

Input Voltage: 100V~, 110-120V~, 50/60Hz; 220-240V~, 50/60Hz or DC24V

Dimensions: (width x depth x height): 19.0" x 7.7" x 1.7" (483 x 195 x 44 mm)

Weight: 2.9 kg (6.4 lbs)



Product Details
DN-312X 12 Denon 12 Canali Rackmixer Professionale
